Part No. | DC
Spark-over Voltage 100V/S(V) | Max.
Impulse Spark-over Voltage 1KV/μs(V) | Normal Discharge Current(L) 1s,50Hz(A) | Normal
Impulse Discharge Current 8x20μs(kA) | Insulation Resistance min. (GΩ)/(Vdc) | Max. Capacitance C 1MHz(pF) |
JTN28-075K | 75±30% | 600 | 20 | 20 | 1GΩ/50Vdc | 1.5 |
JTN28-090K | 90±20% | 600 | 20 | 20 | 1GΩ/50Vdc | 1.5 |
JTN28-150K | 150±20% | 600 | 20 | 20 | 1GΩ/50Vdc | 1.5 |
JTN28-200K | 200±20% | 700 | 20 | 20 | 1GΩ/100Vdc | 1.5 |
JTN28-230K | 230±20% | 700 | 20 | 20 | 1GΩ/100Vdc | 1.5 |
JTN28-250K | 250±20% | 700 | 20 | 20 | 1GΩ/100Vdc | 1.5 |
JTN28-350K | 350±20% | 1000 | 20 | 20 | 1GΩ/100Vdc | 1.5 |
JTN28-420K | 420±20% | 1000 | 20 | 20 | 1GΩ/100Vdc | 1.5 |
JTN28-470K | 470±20% | 1200 | 20 | 20 | 1GΩ/100Vdc | 1.5 |
JTN28-500K | 500±20% | 1200 | 20 | 20 | 1GΩ/100Vdc | 1.5 |
JTN28-600K | 600±20% | 1400 | 20 | 20 | 1GΩ/100Vdc | 1.5 |
