Part No. | DC
Spark-over Voltage 100V/S(V) | Max.
Impulse Spark-over Voltage 1KV/μs(V) | Normal Discharge Current(L) 1s,50Hz(A) | Normal
Impulse Current 8x20μs(kA) | Insulation Resistance min. (GΩ)/(Vdc) | Max. Capacitance C 1MHz(pF) |
JTS3216-075 | 75±30% | 700 | 1 | 0.5 | 100MΩ/50Vdc | 0.5 |
JTS3216-090 | 90±30% | 700 | 1 | 0.5 | 100MΩ/50Vdc | 0.5 |
JTS3216-140 | 140±30% | 700 | 1 | 0.5 | 100MΩ/50Vdc | 0.5 |
JTS3216-150 | 150±30% | 700 | 1 | 0.5 | 100MΩ/50Vdc | 0.5 |
JTS3216-200 | 200±20% | 700 | 1 | 0.5 | 100MΩ/100Vdc | 0.5 |
JTS3216-230 | 230±20% | 800 | 1 | 0.5 | 100MΩ/100Vdc | 0.5 |
JTS3216-300 | 300±20% | 900 | 1 | 0.5 | 100MΩ/100Vdc | 0.5 |
JTS3216-350 | 350±20% | 1000 | 1 | 0.5 | 100MΩ/100Vdc | 0.5 |
JTS3216-400 | 400±20% | 1000 | 1 | 0.5 | 100MΩ/100Vdc | 0.5 |
JTS3216-470 | 470±20% | 1200 | 1 | 0.5 | 100MΩ/100Vdc | 0.5 |
JTS3216-500 | 500±20% | 1200 | 1 | 0.5 | 100MΩ/100Vdc | 0.5 |
