Part No. | DC Spark-over Voltage 100V/S(V) | Max.Impulse Spark-over Voltage 1KV/μs(V) | Normal Discharge Current(L) 1s,50Hz(A) | Normal Impulse Discharge Current 8x20μs(kA) | Insulation Resistance min. (GΩ)/(Vdc) | Max. Capacitance C 1MHz(pF) |
JGS5026-140A | 140±30% | 650 | 2 | 1.0 | 100MΩ/50Vdc | 1 |
JGS5026-200A | 200±20% | 700 | 2 | 1.0 | 100MΩ/100Vdc | 1 |
JGS5026-300 | 300±20% | 900 | 2 | 0.5 | 100MΩ/100Vdc | 1 |
JGS5026-400 | 400±20% | - | 2 | 0.5 | 100MΩ/250Vdc | 1 |
JGS5026-500 | 500±20% | - | 2 | 0.5 | 100MΩ/250Vdc | 1 |
JGS5026-600 | 600±20% | - | 2 | 0.5 | 100MΩ/250Vdc | 1 |
