Model | Current Rating （A） | Voltage Rating (Vdc) | Interrupting Rating | Max. Voltage Drop(mV) | Cold Resistance (mΩ) | Housing Material Color |
JFP0891-2A | 2.0 | 32 | 1000A@32Vdc | 200 | 36.6 | 灰色 |
JFP0891-3A | 3.0 | 32 | 175 | 31.24 | 深紫色 | |
JFP0891-5A | 5.0 | 32 | 175 | 17.0 | 橙色 | |
JFP0891-7.5A | 7.5 | 32 | 150 | 11.3 | 褐色 | |
JFP0891-10A | 10.0 | 32 | 125 | 8.60 | 红色 | |
JFP0891-15A | 15.0 | 32 | 125 | 6.25 | 浅蓝色 | |
JFP0891-20A | 20.0 | 32 | 125 | 4.50 | 黄色 | |
JFP0891-25A | 25.0 | 32 | 110 | 3.67 | 透明色 | |
JFP0891-30A | 30.0 | 32 | 100 | 3.10 | 浅绿色 | |
JFP0891-35A | 35.0 | 32 | 90 | 2.75 | 紫色 | |
JFP0891-40A | 40.0 | 32 | 85 | 2.43 | 酒红色 |
